MAG544w3 x20 Pack

The product you selected is currently unavailable.

Orig. Price: $2,240.88
Sale Price: $1,792.70
Availability: in stock
Prod. Code: MAG544w3x20

Units will be shipped with regionally adapted power supplies.

No subscriptions, TV channels or any other video/audio content will be provided with purchasing of the unit.

Not for resale.

MAG544w3 x 5 pack MAG544w3 x 5 pack

MAG544w3 x 20 pack

Infomir has a special deal for IPTV/OTT operators: a multipack of twenty MAG544w3 devices at an amazing price. With this multipack offer, you can offer your subscribers one of the latest, most powerful set-top boxes that will allow them to play content using all current video formats.
At the heart of MAG544w3 is the advanced Amlogic S905Y4-B processor coupled with the Linux OS. This powerful duo makes the device easy to operate and super-reliable. In fact, it will run continually for many months without needing a reboot. Therefore, users can enjoy their favorite content without delving into the device settings.


MAG544w3 x 5 pack

MAG544w3 streams content in 4K HDR quality at 60 frames per second. The result is crisp, colorful, and lifelike imagery that immerses viewers deep into the action, regardless of what is being watched.


MAG544w3 offers both cable and wireless internet connection options. The integral Ethernet cable port provides data transfer rates of up to 100 Mbps for ultimate speed and stability. For users who prefer a wireless connection, the device can be connected to the internet using the built-in Wi-Fi module, which uses the 2.4 GHz and 5 GHz frequency bands. These provide transfer rates of up to 100 Mbps and 550 Mbps, respectively.


It is possible to connect various external peripheral devices to the MAG544w3 thanks to two USB 2.0 ports. So, if your users wish to control their device via a mouse or a keyboard, they can. Moreover, removable storage media can be connected.


MAG544w3 x 5 pack

Eight-channel Dolby Digital PlusTM support allows MAG544w3 users to connect the device to compatible TVs or HiFi equipment and be immersed in rich surround sound to rival the best movie theaters.


Our twenty-device MAG544w3 multipacks offer exceptional value and provide you with one of the most up-to-date set-top boxes available. To order yours, please don’t hesitate to contact our sales team.


Width/depth/height, (mm) 115x115x28
Weight, g 170
Chipset Amlogic S905Y4
Processor Quad-core ARM Cortex-A35, 2,000 MHz
Performance 16 500 DMIPS
Flash memory 4 GB eMMC
Operating system Linux 4.9
Middleware supported Pre-integrated Ministra TV platform. Image enhancement with operator’s applications, customization, or full replacement available
  HDMI 2.1, 100 Mbps Ethernet, USB 3.0 × 1, USB 2.0 × 1, built-in 2T2R ac Wi-Fi module
Sources of media content
  PC or NAS, multimedia broadcasts (RTSP, RTP, UDP, IGMP, HTTP), USB devices
Audio & video
Audio сodecs
Audio formats MP3, MPA, M4A, OGG, WAV, AAC
Video modes 2160p, 1080i, 1080p, 720p, 576p, NTSC, PAL
Video сodecs AV1, H.265/HEVC (optional), H.264 (AVC), MPEG-1/2, MPEG-4, XviD, 3D video support
Video containers TS, MTS, AVI, MPEG, MP4, MOV, MKV, M2TS, VOB, 3GP
Image formats JPEG, PNG, BMP, RAW
Subtitles DVB, PGS, SRT, SSA/ASS, SUB, Teletext, WebVtt, closed captioning
Playlist formats M3U, M3U8, PLS, CUE


Standard set
  20 x MAG544w3 set-top boxes, user manual, HDMI cable, power adapter, remote control, 2x AAA batteries, packaging
